Built-in Channel Compressors

Built-in professional digital effector

Two SUB outputs, two AUX outputs & Monitor output

With REC input and output

Smooth 60-millimeter faders

3-band Channel EQ and High-pass Filter

High-performance Microphone Preamplifiers with Switchable Phantom Power

Channels:12 CH Mono+2 CH Stereo

S/N Ratio:≥90dB

Frequency Response:20Hz-20KHz ±1dB

THD:<0.05%

Equalization:

HIGH:12kHz ±15dB

MID:2.5kHz ±15dB

LOW:80Hz ±15dB

Dimension(WxDxH):560x400x85mm

Packing Size(WxDxH):600x510x140mm

Net Weight:7.0Kg

Gross Weight:9.0Kg
